Pyrophyllite Stone Crushing Plant

Pyrophyllite Stone Crushing Plant

High technology, good quality Stone Crusher Plant

  • Input Size:

  • Capacity:

Minerals:

Application Areas:

Get Quotation 021-2023 6178
Pyrophyllite is a kind of clay minerals content, crystal structure of 2:1 layered hydrous aluminum silicate minerals. Chemical structural formula for Al2 【 Si4O10 (OH) 2. Pyrophullite is a fine stone, hardness is low (1-2), lately our company developed pyrophyllite mine reserves of 2 million tons, among them, the aluminum content of 30% - 39%, Fe2O3 + TI2O < 0.2%, suitable for synthetic diamond with blank (mould), ceramics, refractory material, glass fiber, stone carving, etc. It can be widely used in ceramics, metallurgy, building materials, chemical industry, light industry and other industrial sectors.

crushing plant

Pyrophyllite stone crushing plant, which is designed by our engineers and technicians on the basis of multiple innovation, test and experience over two decades, has absorbed many advantages of home and abroad mill manufacturing technique. It has been proved by thousands of customers that our machine has outstanding features and stable quality. Our pyrophullite stone crushing plant can upgrade its production and the additional value which is suitable for our customer to use. It is the ideal equipment for fine milling.

pyrophyllite stone crushing plant mainly consists of main unit, classifier, powder collector, dust cleaner, induced draft fan, muffler, sound-proof room, crusher, bucket elevator, storage hopper, and vibrating feeder.

After crushed by hammer crusher, the large materials become small ones and are sent to storage hopper by elevator, and then evenly sent to the upper distribution plate of the turn plate by vibrating feeder and sloping feeding pipe.

When the pyrophyllite stone crushing plant is at work, the main bearing and each dial are driven by electromotor of main equipment through reducer, and all the grinding rollers are rolling in the ring channels driving by dial through plunger. The materials are driven to the edge of the turn plate by the centrifugal force and fall down into the crushing plant chambers where the materials are repeatedly pressed, crushed and grinded by the rollers. Then the materials fall into multiple layers abd to be crushed and ground continuously to micro powder.

The high-pressure air blower  constantly inhales air within the grinding mill and, in turn, the airflow which crushed materials are brought to the classifier whose high-speed impeller will screen the airflow: the unqualified particle size will fall and return to thecrushing plant for being reground while the qualified particle size mixed with air will go into the cyclone powdercollector. Most of the qualified powders will fall and exit from the discharging valve at the bottom; a small proportion of the fine powders. with airflow, moves to the dust cleaner, and clings to the surface of the filter bags. At the same time, the fine powders clinging to the surface fall down by the sudden vibration of the filter bags, which is caused by the instantly by the ejected high-pressure gas controlled by the pulse valve.The materials from the above two lots are sent by the conveyor at the bottom to get finished powders packed. Ib addition, filtered clean air will be emitted from the air outlet of muffler in the end.

Features of Pyrophyllite Stone Crushing Plant

1,High Efficiency

Under the  same finished final size and the same motor power, the capacity of pyrophyllite stone crushing plant is twice as much as jet mill, mixing grinder and ball mill, and energy consumption decreased 30%.

2,Long lifecycle of spare parts

The ring and roller are forged by special material with high utilization. Under the same crushing material and finish special size, the life cycle of spare parts is about one year, which is 2-3 times longer than impact mill or turbo mill. Furthermore, the lifetime can reach 2-5 years for grinding calcite carbonate.

3,High safety and reliability

As no rolling bearings or screws in ginding cavity, there are no problems caused by bolts shedding or rapid wear of bearings and seal components.

4,High fineness and flexible adjustment

The final fineness of the grinding materials can be adjusted between 325 meshes and 2500 meshes(47-5 micron), and the product fineness can reach D97≤5micrometre.

5,Environment-friendly

The application of pulse bag filter and muffler greatly alleviates dust pollution and noise.

6,Advanced intelligent speed control device

Convenient adjusting, more uniform particle size.

Technical data of  pyrophyllite stone crushing plant

Model HGM80 HGM90 HGM100 HGM100A HGM125
Ring Diameter(mm) 800 900 1000 1000 1250
Ring Number/pcs 3 3-4 3-4 4 4
Roller Number/pcs 21 24-32 27-36 27-36 40-44
Main Shaft Speed/r. p. min 230-240 200-220 180-200 180-200 135-155
Input Size/mm ≦15
Finished Size/um 5-47(325-3000)
Capacity t/h 0.4-4.5 0.4-5.5 0.4-6.5 0.4-7.5 0.7-10
Outlet Size L*W*H/m 13.9*4*6.2 14.7*4.8*7.2 18*4.6*8.6 18*4.6*8.6 14*9*10.25
